Micro T-2 Med 39 mm Spacer Och LRP Montage

The Aimpoint® Micro T-2 redefines everything you thought you knew about compact red dot sights. Cutting edge lens coatings radically improve the shape and clarity of the 2 MOA red dot and physical protection has been added for even more ruggedness.

Aimpoint listened to feedback coming from hard-core customers desiring an even more hard core Micro sight. With a redesigned and reinforced house body, as well as flip-up covers protecting the lenses, the Aimpoint® Micro T-2 can withstand all types of environmental conditions.

At the same time, Aimpoint decided to improve upon the optical performance of the sight which results in a new lens and an important breakthrough in reflective lens coatings. This makes the Micro T-2 and the 3XMag magnifier a fantastic optical combination.

Unique Features

• Advanced optical lenses for even better light transmission
• Front Flip-up lens cover is included
• Transparent rear Flip-up lens cover is included Reinforced protection of the turrets for even greater ruggedness
• Ideal for rifles, carbines, shotguns, submachine guns, and handguns
• Weight 3.7 oz. (105g) including mount, sight only 3.0 oz. (84g)
• 1x (non-magnifying) parallax free optic
• Compatible will all generations of Night Vision Devices (NVD) 1 Off position, 4 night vision compatible settings and 8 daylight settings – one extra bright for use with laser protection glasses or in bright desert sunlight
• Integral Picatinny-style base allows easy attachment to any rail ACET technology allows 50,000 hours (over 5 years) of constant operation with one battery
• Available in 2 MOA dot size
• Hard anodized non-reflective finish
• Submersible to 80 feet (25 meters) Use as a standalone sight or piggybacked on larger magnifying, thermal, or night vision optics

Technical Specifications

Optical Specifications

• Operating principle: Reflex collimator sight with LED
• Optical magnification: 1x
• Aiming dot size: 2 MOA
• Dot intensity: Visible against a background luminance of 0.1 to 55 000 lx
• Optical signature: No optical signature is visible at 10 meter distance, front side, on appropriate settings with NVD 3
• Dot color: Peak Wavelength: 655 ± 10 nm
• NVD compatible: Yes
• Optical coating: Anti-reflex, all surfaces and multi-layer. NVD-Compatible 1, 2, 3
• Clear aperture: 18 mm
• Eye relief: Unlimited

Power Source

• Battery type: 3V lithium battery, type CR2032.
• Battery life - Day time use: 5 years (50 000h) of continuous use at pos. 8 and over 10 months at pos. 10. Responds to >500 000 hours at NVD setting (pos. 2)
• Power intensity: 4 NVD and 8 Daylight, of which 1 extra bright

Physical Specifications

• Length sight only: 68 mm (2 5/8")
• Length conf: 79 mm (3 1/16")
• Width: 41 mm (1 9/16")
• Height sight only: 36 mm (1 3/8")
• Height conf: 47 mm (1 13/16")
• Weight sight only (incl battery): 94 g, (3,3 oz)
• Weight conf: 130 g (4,6 oz) incl. Lens Covers and Mount
• Housing material: High Strength Aluminum
• Housing finish and color: Matte black
• Material mount and spacer std conf: High Strength Aluminum
• Surface treatment: Hard anodized, matte
• Height of optical axis - sight and mount: 20 mm (3/4") over top surface of Picatinny/Weaver Rail
• Height of optical axis - sight, mount and Micro spacer XX: Spacer low: 50 mm (1 15/16") over top surface of Picatinny/Weaver Rail
• Height of optical axis - sight, mount and Micro spacer ZZ: Spacer high: 59 mm (2 5/16") over top surface of Picatinny/Weaver Rail
• Adjustment: Range ±1 m at 100 meters (±1 yds at 100 yds) in windage and elevation, 1 click = 13 mm at 100 meters = 10 mm at 80 meters = 7/16" at 100 yds

Environmental Specifications

• Temperature range operation: -45°C to 71°C (-49°F to 160°F)
• Temperature range storage: -51°C to 71°C (-60°F to 160°F)
• Temperature shock: Operable after a temperature shock between -45°C and +71°C. Duration: 4h of Hot +71°C, 4h of Cold -45°C. Cycling: 3 times
• Humidity: Operates despite humidity. Limits: RH: 95%, Temp: 20ºC to 50 ºC, cyclic
• Immersion, static: Operates after immersion. Limits: Depth: 25m (83 ft.)
• Shock: The unit is operable before and after shock. Limits: X-axis: 500 g, 0.7 – 1.1 ms (3 shocks), Y-axis: 40g ±4g, 11 ±1ms (2 shocks in each direction, Z-axis: 40g ±4g, 11 ±1ms, 2 shocks in each direction. Functional during exposure (room temperature)
• Vibration: The unit operates despite vibration. Limits: Vibration, sinusoidal in a frequency range of 10-150 Hz. Frequency: 10-30 Hz, ±1.587 mm, Frequency: 30-150 Hz. 5.75 g, 1 octave/min
• Chemical resistance: Withstands occasional contamination of: Hydraulic oil (FSD 8407, Tryckolja 021), Lubricating oil (FSD 8127, Motorolja 5W/30), Lubricating oil (FSD 8220, Smörjfett 220), Lubricating oil (Break Free), Fuels (FSD 8612, Diesel fuel oil), Solvents/cleaning (FSD
• Mechanical Interface
• Keyed surface mount: Integrated
